Istil OB van

With the Istil production house and outside broadcaster (Ukraine) we designed, planned and realised a innovative 16-camera OB truck for producing sports, events and shows. Istil, based in Kiev, has been active in the mobile production business since 1991. With the Istil "White" OB the company is further expanding its efforts in outside broadcasting.



Technical Synopsis:

1. Video

 - Up to 20 cameras, triax or hybrid

- 3ME vision mixer with 34 inputs

- Character generator

- Multiviewer with LCD panels

- 5 recording devices (VTRs/HDD recorders)

- Slow Motion with integrated server

- Router 128x128



2. Audio

-Separate isolated rooms for main audio console & operator, and for concert console & operator

-Main and backup consoles, 5.1

-Intercom matrix, wired panels, wireless belt packs



3. Coach

-Length (without tracktor) - 13,4m

-Width (travel) - 2,55m

-Width (expanded) - 3,75m

-Height - 4m



4. Other

- One-side expansion

- Hydraulic jacks

- Redundant air conditioning systems - 2 double power feeds

- UPS for 15 min operation

- Motorised drums for triax and power cables

- Noise isolating rack room

- additional interior floor  heating

- Exterior mechanics heating, preparation for cold climate
